Handheld Reader android
BRD-C02 RFID Handheld Reader is suitable for retail industry, library management, archives management, power industry, asset management, vehicle management, warehousing and logistics, manufacturing, medical industry, etc
HomeProductsHandheld RFID Readers
Overview Specification Applications Recommend

Handheld Reader android

RFID Handheld Reader Android

Impinj E710 platform;

Support ISO18000-6C protocol;

RJ-45 and RS-232;

Independent mold opening, all-aluminum die-casting, efficient heat dissipation;

Support RSSI, can perceive the signal strength;

Support antenna detection function;

Get Quote
Do you need to view the product specification?

You can click to view more about product information

Explore

Highlight
Specifications
  • Performance
    CPU Octa-core 2.0GHz
    Operating System Android11
    RAM +ROM 4GB+64GB (optional 6GB RAM + 128GB ROM)
    Card slot SIM+TF
    PSAM*1（micro card）(optional)
    Storage Expansion Micro SD card, up to 256GB support
    Interfaces/Communications Water-resistant Type-C USB interface, supporting USB 2.0 High Speed OTG
    Keypad Power button, Volume buttons (+/-), Scan buttons*2, + Customizable buttons
    Display 5.5-inch capacitive touch screen
    1440(H)×720(W)
    Power 5000mAh
    Type C USB connector, supports QC3.0 fast charging
    Notification Sound, Vibration, LED indicator
    Audio Single speaker, Dual microphones (with noise cancellation)
    Sensor G-sensor, Light sensor, Proximity sensor, Gyroscope
    Dimensions 156*76*14（UHF top 28.2）mm
    Weight 335g (including battery)
    Operating Temperature -20°C to +50°C
    Storage Temperature -40°C to +60°C (with battery)/-40°C to +70°C (without battery)
    Humidity 5% to 95% RH, non-condensing
    Protection Grade IP67
    Drop Resistance 1.5m onto smooth marble
    (ESD) ±15KV air discharge, ±8V conductive discharge
  • data collection function parameters
    Optical Resolution 1280 x 1080 pixels
    Tilt Angle ±60° from normal angle
    Skew Angle ±55° from normal angle
    Laser safety Class Class II
    Image Frame Rate 60fps
    Supported 1D：UPC/EAN, UPC/EAN , Code128, GS1-128, Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, Industrial2 of 5,Codabar, MSI ,Code11Symbologies
    2D：PDF417, MicroPDF417,Data Matrix, Maxicode, QR Code,MicroQR, Aztec
    Illumination and Projection Warm color light, laser projection
    Minimum Print Contrast 20%
    Maximum Resolution 4224*3136
    Pixel Count 13MP
    Camera Functions PDAF phase detection autofocus
    Flash and Fill Light Supported
    Maximum Resolution 2592*1944
    Pixel count 5MP
    Camera Functions Fixed focus
    Positioning System GPS+GLONASS+BeiDou, supporting AGPS
    Frequency GPS as the main positioning, BeiDou and GLONASS as auxiliary
    Accuracy GPS: L1/L5; BeiDou: B1; GLONASS: L1/L5
  • Wireless Data Communication Function Parameters
    Protocol IEEE 802.11a/b/g/n/ac/ax ready（2.4G/ double band 5GWIFI）
    Frequency Range Depending on country/region, 2.4GHz: 2.412GHz - 2.472GHz; 5GHz: 5.180GHz - 5.825GHz
    Working Channels CH1~CH13, CH36-CH140, CH149~CH165
    Security Supports WPA2-Personal, WPA2-Enterprise, EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-AKA Prime
    Frequency GSM：Qual Band(850/900/1800/1900Mhz)
    WCDMA：Band2，Band4，Band5，Band8
    TDD-LTE：Band38，Band39，Band41
    FDD-LTE：Band2，Band4，Band 5，Band7，Band8，Band12， Band 17 ,Band13，Band25，Band26，Band66 ,Band71
    Standard Bluetooth 5.1 (supports BLE)
    Power Class Class II
  • RFID Function Parameters
    Supported Tags Compliant with ISO-18000-6C/EPCC1G2
    Antenna Parameters 0.5dBiC circular polarization, supporting 902-928MHz
    Working Frequency 840-960MHz (customizable based on local regulations, default is 902-928MHz)
    Working Mode Frequency Hopping Spread Spectrum (FHSS) or fixed frequency
    Output Power 1~30dBm
    Read Distance ≥3m @9662 white card (practical distance affected by tag and environment)
    Write Distance 0~1.5m @9662 white card (practical distance affected by tag and environment)
    Group Read Speed Maximum 700 tags/second @impinj H47 (actual distance affected by tag and environment)
    Read Speed Average 12ms per 32-bit word
    Write Speed Average 60ms per 32-bit word
    Power Consumption Average power <4.5W
  • Third-Party Application Development Support
    Operating System Android 11
    Programming Environment Eclipse, Android Studio
  • External Devices and Accessories
    Standard Power Adapter x1, Type C Data Cable x1
    Optional Single Cradle Charger, 4-Bay Battery Charger, OTG Cable, Wrist Strap
Applications
RFID Apparel & Footwear retail solution
Apparel & Footwear
RFID Apparel & Footwear retail solution
RFID shoe and apparel retail solutions to reshape the new retail experience. Using RFID technology, it is easy to realize the automatic tracking and management of shoes and clothing products, accurate inventory, rapid inventory, and effective prevention of theft. The program makes the store operation more smooth, and the customer shopping more convenient, and is the best choice for the intelligent transformation of the shoe and clothing retail industry.

View More
RFID store cash register
Apparel & Footwear
RFID store cash register
RFID store cashier solution, through intelligent RFID tags to achieve rapid identification of goods, improve cashier efficiency, reduce customer waiting time. Real-time inventory synchronization, accurate management of commodity flow. At the same time, data analysis helps precision marketing and promotes store performance.

View More
RFID intelligent book management
Library & Archives
RFID intelligent book management
RFID intelligent book management solution uses RFID technology to give each book a unique identity to achieve automatic identification and tracking. Readers borrow and return more convenient, book inventory and search efficiency doubled. At the same time, the intelligent analysis system helps the library to accurately grasp the collection situation and optimize the allocation of resources. Make the library management more efficient and intelligent, and create a more comfortable and convenient reading environment for readers.

View More
RFID Warehous and logistics management
Warehousing & Logistics
RFID Warehous and logistics management
RFID logistics warehousing management solution through the integration of RFID technology, to achieve the whole chain of intelligent management of goods from warehousing to warehousing. RFID tag accurate identification, real-time tracking of goods location and status, reduce manual errors, improve work efficiency. Automated inventory and inventory monitoring to ensure inventory accuracy and reduce operating costs. At the same time, data-driven decision-making helps enterprises accurately optimize warehousing layout and operational strategies.

View More
